PTFE (Polytetrafluoroethylene)
BAG FILTER SPECIFICATION |
For DF-12 |
For DF-16 |
For DF-22 |
|
16 ton/H |
22 ton/H |
No. |
Item |
Unit |
|
Model-LCDM175-6-16 |
Model-LCDM175-6-22 |
1 |
Cleaning Type |
|
Off-line low-pressure pulse jet |
Off-line low-pressure pulse jet |
Off-line low-pressure pulse jet |
2 |
Number of chamber |
|
3 |
6 |
6 |
3 |
Filtration surface |
m2 |
525 |
880 |
1230 |
4 |
Smoke capacity disposed |
m3/h |
30000 |
45000 |
60000 |
5 |
Face Velocity
Off Line face velocity |
m/min |
0.85 |
0.85 |
0.61 |
m/min |
1.08 |
1.02 |
0.88 |
6 |
Bags |
Specification |
mm |
dia. 130 x 4000 |
dia.130 x 6000 |
dia. 130 x 6000 |
Quantity |
|
324 |
360 |
504 |
Media |
|
PTFE (polytetrafluoroethlene) |
PTFE (polytetrafluoroethlene) |
PTFE (polytetrafluoroethlene) |
7 |
Resistance |
pa |
1500 |
1500 |
1500 |
8 |
Fabric heat resistance (Continuous) |
oC |
250 |
250 |
250 |
| (Peak) |
oC |
280 |
280 |
280 |
9 |
Exhaust Gas temperature from boiler |
oC |
150-180 oC |
150-180 oC |
150-180 oC |
10 |
outlet dust Concentration |
g/Nm3 |
20 |
20 |
20 |
11 |
inlet dust Concentration |
mg/Nm3 |
50-150 |
50-150 |
50-150 |
12 |
Pulse Valve |
Specification |
|
3" |
3" |
3" |
Quantity |
|
18 |
24 |
36 |
Pressure of source compressed |
Mpa |
0.20'0.3 |
0.25'0.3 |
0.2' 0.3 |
Blowing time |
sec |
0.05 to 0.1 adjustable |
0.08 ' 0.15 adjustable |
0.05' 0.1 adjustable |
Interval of Blowing time |
sec |
5 to 99 adjustable |
5 '20 adjustable |
0' 99 adjustable |
Air Consumption of Blowing |
m3/valve |
0.25 to 0.3 |
0.25 '0.3 |
0.25' 0.3 |
Air-supply from the soruce |
m3/min |
about 1.0 to 3.0 |
about 1.0 '3.0 |
about 1.0 '3.0 |
13 |
Elevating Wave |
Specification |
m3/min |
dia.550 |
dia.550 |
dia.800 |
Quantity |
|
3 |
6 |
6 |
PTFE (Polytetrafluoroethylene)
BAG FILTER SPECIFICATION |
For SHL-35 |
For SHL-75 |
35 ton/H |
75 ton/H |
| No. |
Item |
Unit |
Model-LCDM175-8-35 |
Model-LCDM175-16-75 |
| 1 |
Cleaning Type |
|
Off-line low-pressure pulse jet |
Off-line low-pressure pulse jet |
| 2 |
Number of chamber |
|
8 |
16 |
| 3 |
Filtration surface |
m2 |
1600 |
3200 |
| 4 |
Smoke capacity disposed |
m3/h |
91000 |
18000 |
| 5 |
Face Velocity
Off Line face velocity |
m/min |
0.94 |
0.94 |
| m/min |
1.08 |
1.08 |
| 6 |
Bags |
Specification |
mm |
dia. 130 x 4000 |
dia.130 x 6000 |
| Quantity |
|
640 |
1280 |
| Media |
|
PTFE (polytetrafluoroethlene) |
PTFE (polytetrafluoroethlene) |
| 7 |
Resistance |
pa |
1500 |
1500 |
| 8 |
Fabric heat resistance (Continuous) |
oC |
250 |
250 |
| (Peak) |
oC |
280 |
280 |
| 9 |
Exhaust Gas temperature from boiler |
oC |
150-180 oC |
150-180 oC |
| 10 |
outlet dust Concentration |
g/Nm3 |
20 |
20 |
| 11 |
inlet dust Concentration |
mg/Nm3 |
50-150 |
50-150 |
| 12 |
Pulse Valve |
Specification |
|
(2-1/2)" |
(2-1/2)" |
| Quantity |
|
40 |
80 |
| Pressure of source compressed |
Mpa |
0.2' 0.3 |
0.2' 0.3 |
| Blowing time |
sec |
0.05' 0.1 adjustable |
0.05' 0.1 adjustable |
| Interval of Blowing time |
sec |
0' 99 adjustable |
0' 99 adjustable |
| Air Consumption of Blowing |
m3/valve |
0.25' 0.3 |
0.25' 0.3 |
| Air-supply from the soruce |
m3/min |
about 1.0 '3.0 |
about 1.0 '3.0 |
| 13 |
Elevating Wave |
Specification |
m3/min |
dia.800 |
dia.800 |
| Quantity |
|
8 |
16 |
